MR-PV600 series PV Surge Protective Device 40KA DC 1000V SPD suitable for the new energy wind power generation system,its working voltage covers 500V,800V and 1000V.It is installed in the main power system at DC circuit,to protect against the indirect lighting current,direct lighting current or other instantaneous over voltage.
| solar surge protector | MR-PV600 | MR-PV1000 | |||
| PV DC specific (IEC 6614-1/EN 61643-11) | |||||
| Pole | 2 pole | 3 pole | |||
| Electrical Parameter | |||||
| Classifical test | II | II | |||
| Uoc max (V DC) | 550 | 600 | 800 | 1000 | |
| Uc (V DC) | 550 | 600 | 1000 | 1000 | |
| In(8/20)us (KA) | 20 | 20 | |||
| Imax(8/20)us (KA) | 40 | 40 | |||
| Up (KV) | 2 | 3.8 | |||
| Remote control and indication | |||||
| Indication window | |||||
| Plug-in module | |||||
| Remote signal contact | |||||
| Remote signal contact | Max working volt | 250V AC/30V DC | 250V AC/30V DC | ||
| Max working amp 1A (250V/AC) | 1A (250V/AC) | 1A (250V/AC) | |||
| 1A (30V DC) | 1A (30V DC) | 1A (30V DC) | |||
| Wiring & installation | |||||
| Wiring capacity(mm2) | Hard wire | 4-25mm | 4-25mm | ||
| Flexible wire | 4-16mm | 4-16mm | |||
| Stripping length | 10 | 10 | |||
| Terminal screwa | M5 | M5 | |||
| Torque(Nm) | Main ciruit | 3.5 | 3.5 | ||
| Remote signal contact | 0.25 | 0.25 | |||
| Protection class | All profile | IP40 | IP40 | ||
| Connection port | IP20 | IP20 | |||
| Installation environment | No obvious shock and vibration | ||||
| Altitude(m) | ≤ 2000 | ≤ 2000 | |||
| Working temperature | 67 | 67 | |||
| Relative humidity | 30%-90% | 30%-90% | |||
| How to install | Install with H35-7.5/DIN35 stell mounting rail | ||||
| Size(mm) (W*H*L) | W | 36 | 54 | ||
| H | 90 | 90 | |||
| L | 48.5 | 48.5 | |||
| Weight (KG) | 0.28 | 0.42 | |||
| Weight | 22.5 kg |
|---|
